£136.00
Please choose options to view available calibrations and pricing
Graduation 0.001 mm This is a one revolution dial indicator. It offers you the following benefits:
Bezel clamp and lifting lever (optional) can be attached to either right or left side.
No through screw holes on the frame as well as the use of an O-ring prevents water or oil penetration.
It eliminates the possibility of reading errors due to miscounting multiple revolutions.
| Weight | 140 g |
|---|---|
| Family | |
| Unit | |
| Calibration Type | |
| Indicator Type | Plunger Type |
| Range (mm) | |
| R MPE (Repeatability) (µm) | 1 |
| Graduation (mm) | |
| Standard | |
| MPE measuring range (µm) | 3 |
| Range per rev. (mm) | 0.1 mm |
| MPE any 1/10 revolution | 2 |
| One revolution | Yes |
| Stem (mm) | |
| Digital/Analog | |
| Shockproof | Yes |
| Contact point |
