SKURange (inch)Range (mm)Price
543-554E0 - 20 - 50.8

Add to Basket

Prices in the above table do not include calibration.

Description

A Mitutoyo back-lit screen type digital indicator, mains-powered. ABSOLUTE System scale for error free, high-speed measurement. Functionality includes an analogue bar scale, switchable resolution, colour-coded tolerance judgement, Max/Min data hold and Runout measurement. SPC data output.

Specification

Weight 330 g
Family

Unit

Calibration Type

Indicator Type

Plunger Type

Range (inch)

Range (mm)

Graduation (inch)

Graduation (mm)

Standard

Digital step (mm)

Digital step (inch)

H MPE (Hysteresis) (mm)

0.002 mm

H MPE (Hysteresis) (inch)

0.0001"

R MPE (Repeatability) (mm)

0.002 mm

R MPE (Repeatability) (inch)

0.0001"

Measuring force

Protection

Scale

Electrostatic capacitance type absolute linear encoder

Stem Ø (mm)

Alarm

Counting value composition error, overflow error, tolerance limit setting error

Display

Contact point

,

Power supply

AC adapter 9V DC, 500mA

Inch/Metric switchable

Yes
