£749.00 – £862.00
Please choose options to view available calibrations and pricing
| SKU | Range (inch) | Range (mm) | Price | ||
|---|---|---|---|---|---|
| 543-562E | 0 - 1.2 | 0 - 30.4 | £749.00 |
| |
| 543-564E | 0 - 2.4 | 0 - 60.9 | £862.00 |
|
Prices in the above table do not include calibration.
A Mitutoyo back-lit screen type digital indicator, mains-powered. Extensive functionality includes an analogue bar scale, switchable extra-high resolution, colour-coded tolerance judgement, Max/Min data hold, Runout measurement and function lock. Digimatic data output.
RS-232 input / output is applicable with appropriate connecting cable (1m: 21EAA130 or 2m: 21EAA131)
| Weight | 290 g |
|---|---|
| Family | |
| Unit | |
| Calibration Type | |
| Indicator Type | Plunger Type |
| Range (inch) | |
| Range (mm) | |
| Graduation (inch) | |
| Graduation (mm) | |
| Standard | |
| Digital step (mm) | |
| Digital step (inch) | |
| Max. response speed (mm/s) | 1000 |
| H MPE (Hysteresis) (mm) | 0.0015 mm, 0.0025 mm |
| H MPE (Hysteresis) (inch) | 0.00006", 0.0001" |
| R MPE (Repeatability) (mm) | 0.001 mm |
| R MPE (Repeatability) (inch) | 0.00004" |
| Measuring force | |
| Protection | |
| Scale | Photoelectric linear encoder |
| Stem Ø (mm) | |
| Alarm | Counting value composition error, overflow error, tolerance setting error |
| Display | |
| Contact point | |
| Power supply | AC adapter 6 V DC, 2A |
| Inch/Metric switchable | Yes |
