£749.00 – £862.00
Please choose options to view available calibrations and pricing
| SKU | Range (mm) | Price | ||
|---|---|---|---|---|
| 543-561E | 0 - 30.4 | £749.00 |
| |
| 543-563E | 0 - 60.9 | £862.00 |
|
Prices in the above table do not include calibration.
This is a superior multi-function indicator that gives you high accuracy and high resolution of 0.0005mm. The Digimatic Indicator ID-H offers you the following benefits: 2-colour LCD backlight (green and red) provides you with visual GO/±NG tolerance judgement and analogue bar-graph display. You can display the maximum, minimum or range (runout value). Lifting mechanism over 30mm with cable release (optional). You can carry out zero-setting and presetting with the optional remote controller, without having to touch the indicator. The remote control system can be implemented in advance with the built-in RS-232 interface and a PC. External power supply via AC-Adapter.
RS-232 input / output is applicable with appropriate connecting cable (1m: 21EAA130 or 2m: 21EAA131)
| Weight | 290 g |
|---|---|
| Family | |
| Unit | |
| Calibration Type | |
| Indicator Type | Plunger Type |
| Range (mm) | |
| Graduation (mm) | |
| Standard | |
| Digital step (mm) | |
| Max. response speed (mm/s) | 1000 |
| H MPE (Hysteresis) (mm) | 0.0015 mm, 0.0025 mm |
| R MPE (Repeatability) (mm) | 0.001 mm |
| Measuring force | |
| Protection | |
| Scale | Photoelectric linear encoder |
| Stem Ø (mm) | |
| Alarm | Counting value composition error, overflow error, tolerance setting error |
| Display | |
| Contact point | |
| Power supply | AC adapter 6 V DC, 2A |
