From £703.00
Calibration options available
| SKU | Range (mm) | Measuring Contact | Price | ||
|---|---|---|---|---|---|
| 209-400 | 0 - 10 | Carbide ball Ø 1.5 mm, Ø 3 mm (209-911) | £703.00 |
| |
| 209-401 | 0 - 10 | Carbide ball Ø 1.5 mm & Bevel radius 0.4 mm | £703.00 |
| |
| 209-402 | 0 - 10 | Carbide ball Ø 1.5 mm, Ø 3 mm (209-911) | £703.00 |
| |
| 209-403 | 0 - 10 | Disk measuring faces Ø 6 mm | £703.00 |
| |
| 209-404 | 0 - 20 | Carbide ball Ø 1.5 mm, Ø 3 mm (209-911) | £703.00 |
| |
| 209-405 | 0 - 20 | Bevel radius 0.4 mm (209-405), 0.75 mm (209-921) | £703.00 |
| |
| 209-406 | 0 - 20 | Carbide ball Ø 1.5 mm & Bevel radius 0.4 mm | £703.00 |
| |
| 209-407 | 0 - 20 | Carbide ball Ø 1.5 mm, Ø 3 mm (209-911) | £703.00 |
| |
| 209-911 | 0 - 50 | Carbide ball Ø 1.5 mm, Ø 3 mm (209-911) | £844.00 |
| |
| 209-912 | 0 - 50 | Carbide ball Ø 3 mm& Carbide ball Ø 3 mm, Bevel radius 0.75 mm (209-922) | £844.00 |
| |
| 209-921 | 0 - 50 | Bevel radius 0.4 mm (209-405), 0.75 mm (209-921) | £896.00 |
| |
| 209-922 | 0 - 50 | Carbide ball Ø 3 mm& Carbide ball Ø 3 mm, Bevel radius 0.75 mm (209-922) | £844.00 |
|
Prices in the above table do not include calibration.
This analog External Dial Caliper Gauge offers you the following benefits: Excellent resistance against water and dust (IP65 protection level) Optimized measuring force Ergonomically designed to lie securely in your hand when measuring
| Weight | 165 g |
|---|---|
| Family | |
| Calibration Type | |
| Indicator Type | Dial Calliper |
| Range (mm) | |
| Graduation (mm) | |
| Accuracy (mm/µm) | |
| Measuring Contact | Bevel radius 0.4 mm (209-405), 0.75 mm (209-921), Carbide ball Ø 1.5 mm & Bevel radius 0.4 mm, Carbide ball Ø 1.5 mm, Ø 3 mm (209-911), Carbide ball Ø 3 mm& Carbide ball Ø 3 mm, Bevel radius 0.75 mm (209-922), Disk measuring faces Ø 6 mm |
| Measuring force | |
| Hb | 18.8, 19.1, 21.7, 24.6, 24.7, 30 |
| Hf | 0.9, 14.8, 18.6, 2.5, 24.6, 30, 4.6 |
